Control boards, spark modules, relays — through the house wiring
St. Augustine · St. Johns County · Florida
Heavy Viking kitchen equipment, in a town that works against it
A professional range, a built-in refrigerator and a ducted hood are built to outlast the kitchen around them. Here they are asked to do it in salt air, 68 thunderstorm days a year and openings that were cut long before the appliance existed. That is what Anvil & Oak Appliance works on — one manufacturer, this county, nothing else.
Diagnostic $80 Flat, and credited toward the repair on approval.
Warranty 90/365
Days on labour and on parts. Genuine OEM parts.
Condenser fins, door hinges, stainless trim, exposed fasteners
Rear clearance, door square, the appliance’s own control pocket
Hinges, gaskets, ice-maker modules, evaporator fans, relay boards
The short version
The cheapest measurement goes first
Almost everything that comes off the van in St. Johns County traces back to one of the four cells above. What decides the bill is the order the checks run in: the measurement that can eliminate the largest part of the list is taken first, and nothing is ordered until a meter has said so. This is the order a visit actually runs in.
| Complaint | Checked first | Then | Why in that order |
|---|---|---|---|
| Fresh food warm, freezer cold | Evaporator fan and the air path | Defrost heater and bimetal | Both faults present as one warm compartment; the fan settles it in minutes |
| Oven bakes unevenly | Logged probe over three full cycles | Sensor resistance, then the burner or element | A single thermometer reading cannot see swing, and swing is usually the fault |
| Burner sparks but will not light | Electrode gap, insulator, port obstruction | Gas pressure at the manifold | The visible, no-parts fault is also the most common one |
| Upper rack still dirty | Spray-arm holes and the coarse filter | Circulation pump and feed tube | Flow is lost upstream far more often than the pump fails |
| Hood loud but weak | Duct run, roof cap, backdraft damper | Blower wheel and speed control | Delivered airflow is lost in the duct, and no new hood recovers it |
| Dead board, everything else fine | Supply and ground at the outlet | Board, then the harness to it | Surge damage arrives through the wiring, so the wiring is tested first |
Roughly 68 thunderstorm days a year in this part of Florida. Surges reach control boards through the house wiring, not through the appliance. Coastal ZIPs 32084, 32082, 32080 add salt to the condenser and the hardware. Area by area.
Where we go
- Palencia — dishwashers and ice makers · 32095
- Davis Shores — storm-killed boards and salt air · 32080
- Marsh Creek — panelled doors and hinges · 32080
- Camachee Island — condensers and seized hardware · 32084
- World Golf Village — ice makers and control boards · 32092
- SilverLeaf — hoods and makeup air · 32092
What we repair
Viking range and rangetop repair
Sealed burners, infrared broilers, convection bake and door hinges on Viking professional ranges and rangetops.
Viking wall oven and speed oven repair
Built-in single, double and speed ovens. Heat control, convection, door latches and the boards that fail behind them.
Viking built-in and free-standing refrigeration
Columns, side-by-sides, French doors and undercounter units. Sealed systems, defrost faults, ice makers and door alignment.
Viking dishwasher repair
Built-in dishwashers. Wash performance, drainage, leaks, door seals and the flow losses that show up as a dirty upper rack.
Viking ventilation hoods and blowers
Wall, island and liner hoods with internal, inline or remote blowers. Extraction, controls, lighting and duct faults.
Viking outdoor grills and built-in gas
Built-in and cart grills, side burners and rotisseries. Ignition, gas delivery, burner replacement and coastal corrosion.
Viking wine cellars and undercounter refrigeration
Undercounter wine storage, beverage centres and refrigerator drawers. Temperature stability, ventilation, seals and glass doors.
One manufacturer
Viking only. Turning down every other badge is what keeps the parts stock, the service literature and the diagnostic habits sharp.
Trade boundary
One trade, and the one we are mistaken for
Viking is a kitchen appliance manufacturer, and kitchen appliances are the whole of this trade: professional ranges and rangetops, wall and speed ovens, built-in refrigeration, wine storage, dishwashers, ventilation hoods and built-in outdoor grills.
We are not a heating or air-conditioning company. No furnaces, no air handlers, no heat pumps, no mini-splits and no conditioned-air ductwork — the only duct this bench works in is the extraction run above a kitchen hood.
If the badge on the appliance says something else, or the fault is in the heating rather than the kitchen, we say so on the telephone and you are not charged to find out.
On the van
- Professional ranges and rangetops
- Wall ovens and speed ovens
- Built-in and free-standing refrigeration
- Dishwashers
- Ventilation hoods
- Outdoor grills
- Wine cellars and undercounter refrigeration
Kitchen appliances only — no heating, air conditioning or conditioned-air ductwork.
From the bench
Notes, not marketing
- Replacing a Viking Range Burner — A worn Viking burner is normally fixed one part at a time. Read the serial date, name the failed piece, count the repeats, then weigh what reaching it involves.
- Viking Fridge Codes Decoded — Most Viking refrigeration codes are reminders or door alarms an owner can clear in a minute. A handful, led by oPn, Shr, HH and LL, point to a sensor or cooling fault.
- Igniter Clicking, No Flame — Clicking is the spark system working. The fault is between the spark and the gas, and the three usual answers are the three cheapest parts on the appliance.
How a visit runs
- You call and describe the symptom.
- We attend, open the appliance and test it.
- A written estimate, parts and labour on separate lines.
- You approve, or you do not. The $80 stands either way.
EPA Section 608 certified technicians for sealed-system refrigerant work.
Published bands
What does a Viking repair cost in St. Augustine?
A band, not a single number: the firm figure is written down after the appliance has been opened and measured, and a range is what you can act on before that. Parts and labour together, fitted, for the work on this site.
| Repair | Typical range |
|---|---|
| Diagnostic visit | $80 flat |
| Igniter or burner assembly | $210–$560 |
| Oven thermostat or heating element | $180–$610 |
| Control board or touch panel | $410–$980 |
| Refrigeration fan or defrost system | $240–$640 |
| Dishwasher pump or control | $240–$670 |
| Compressor or sealed-system repair | $970–$2,640 |
Flat $80 diagnostic covering the visit and the full diagnostic sequence, credited toward the repair once you approve the work.A written estimate comes before any part is ordered or any labour is billed. The whole published table. Worth fixing, or worth replacing.
Diagnostic$80
Flat, and credited toward the repair on approval.
Repairs on this page$80–$2,640
The span of the bands in the table, fitted. The estimate names the part and the
labour on separate lines before anything is ordered.
Questions people ask before booking
How much does a Viking repair in St. Augustine cost?
The visit is a flat $80 diagnostic, credited toward the repair once you approve it. The repair itself lands in the bands published on this page — igniter or burner assembly $210–$560; oven thermostat or heating element $180–$610; control board or touch panel $410–$980; refrigeration fan or defrost system $240–$640; dishwasher pump or control $240–$670; compressor or sealed-system repair $970–$2,640 — so $80 to $2,640 covers the work described here, parts and labour together. The firm number is written down after the appliance has been measured, never before.
Do you work on anything other than Viking?
No — one manufacturer, the whole line: ranges and rangetops, wall ovens, built-in refrigeration, wine storage, dishwashers, hoods and outdoor grills. If the badge on the door says something else we tell you on the telephone, and you are not charged for a visit to find that out.
Do you repair heating or air conditioning?
No. Viking here is the kitchen appliance manufacturer, not a heating trade — the work is ranges and rangetops, ovens, built-in refrigeration, wine storage, dishwashers, hoods and built-in grills. Furnaces, air handlers, heat pumps and conditioned-air ducting are a different trade altogether, and we say so on the telephone rather than charge $80 to find out.
Is the $80 diagnostic credited?
Flat $80 diagnostic, credited toward the repair when you approve the work. If you decide not to go ahead, the diagnostic stands on its own and you keep the written estimate, including what was measured and what was ruled out.
Not answered here
Ring the bench and describe the symptom. A question that cannot be answered on the telephone is a question that needs a meter on the appliance, and we would rather say so than sell a visit to find out.
Owner verdicts
What owners said afterwards
4.7 out of 5 from 61 customer reviews. Every one below is a single visit, in the words of the person who paid for it.Fresh food side crept up to the high forties while the freezer stayed rock solid. He pulled the lower grille, found the evaporator fan seized with salt crust off the marina air, and swapped it the same visit. No panel got marked.
Delia T.2026-06-11
The rotisserie motor had seized solid in the damp. He fitted a new one and lubricated the spit bearings. The work was fine, though I would have liked a clearer account of why the old one gave up so soon.
Wendy G.2026-06-01
Two burners on the lanai grill would light and the rest would not. He found the ignition module corroded through from ocean air, replaced it along with the electrodes, and told me to keep the cover on between cooks. All burners fire.
Dale W.2026-06-29
Next step
Book a diagnostic
Flat $80 diagnostic, credited toward the repair when you approve the work. A written estimate comes before any part is ordered or any labour is billed.
90 days on labour, 365 days on parts, genuine OEM parts only. Calls placed after hours are returned the next working morning.
Flat rate $80
Diagnostic visit in St. Augustine and St. Johns County. Credited toward the repair.
